PowerField Energy PowerRack Solar PV Ground-Mount System
NOTE: Maximum module width 41.3”/1050mm. Please let us know if you intend to install modules on these measuring between 1010mm and 1050mm in width as special adapter clamps are required in those cases.
PowerField Energy's PowerRack solar PV ground mount is a revolutionary solution for low cost low impact versatile applications. This non-penetrating and tool-less surface mount dramatically reduces installation costs and enables flexible project implementation. This ground mount system allows for easy installation with no digging, no concrete, no ground penetration, no special tools or equipment.
Characteristics:
Includes: One piece rack with two clips
Material: High Density Polyethylene
Warranty: 10 years
Dimensions(LxWxH): 41 x 26 x 25 in
Module Orientation: Landscape
Ballast Material: Any aggregate or solid material
Wind Load: 120 mph ASCE 7-10
Snow Load: 93 psf / 5400 Pa
Expected Lifespan: 40 years
Disposal: Reusable and Recyclable
Ballast Weight Levels:
